Teltonika-RUT200 (Modulo QUECTEL EC200A-EU )-Compact, cost-effective and powerful industrial LTE router for professional applications - MASSPACKING
Code: ART-200486 - RUT200011006
Teltonika - RUT200 - Compact, cost-effective and powerful industrial LTE router for professional applications - MASSPACKING
RUT200 offre le caratteristiche più apprezzate del bestseller Teltonika di sempre RUT240 ed è compatibile con le reti di Asia, CSI, Medio Oriente, Africa e Sud America.
Dotato di 4G LTE, Wi-Fi e due porte Ethernet, questo modello è perfetto per impostare rapidamente la connettività primaria e di backup con funzionalità di gestione remota.
Grazie alle sue dimensioni compatte, al design industriale e agli I/O, questo modello è molto adatto ai settori della produzione, dell'automazione, dei trasporti e ad altri scenari applicativi industriali che richiedono una connettività mission-critical in condizioni rigorose.
Modulo LTE Quectel EC200A-EU
Caratteristiche:
- 1 x SIM slot (Mini SIM – 2FF), 1.8 V/3 V, external SIM holder 4G (LTE) – Cat 4 up to 150 Mbps, 3G – Up to 42 Mbps, 2G – Up to 236.8 kbps
- 1 x WAN port (can be configured to LAN) 10/100 Mbps, comply IEEE 802.3, IEEE 802.3u standards, supports auto MDI/MDIX
- 1 x LAN port, 10/100 Mbps, comply IEEE 802.3, IEEE
- 802.3u standards, supports auto MDI/MDIX
- Frequency: 4G (LTE-FDD): B1, B3, B5, B7, B8, B20, 4G (LTE-TDD): B38, B40, B41, 3G: B1, B5, B8, 2G: B3, B8
- IEEE 802.11b/g/n, Access Point (AP), Station (STA)
- Remote Management System (RMS)
- Power Input: 9 – 30 VDC (4 pin industrial socket), reverse polarity protection, surge protection >33 VDC 10us max
- Passive PoE in over spare pairs (available from HW revision 0007 and batch number 0010). Possibility to power up through LAN port, not compatible with IEEE802.3af and 802.3at
LAN | 1 x LAN port, 10/100 Mbps |
WAN | 1 x WAN |
Mobile module | 4G (LTE) – Cat 4 up to 150 Mbps, 3G – Up to 42 Mbps, 2G |
WiFi | WPA2-Enterprise |
Wireless mode | IEEE 802.11b/g/n, Access Point (AP), Station (STA) |
Ethernet | 2 x RJ45 ports, 10/100 Mbps |
Status LEDs | 3 x connection type status LEDs, 5 x connection strength LEDs, 2 x LAN status LEDs, 1x Power LED |
SIM | 1 x SIM slot (Mini SIM – 2FF, 2st form factor), 1.8V/3V, external SIM holder |
Power | 4 pin DC connector with 1 x Digital input and 1 x Digital output |
Anntenas | 2 x SMA for LTE, 1 x RP-SMA for WiFi antenna connectors |
Reset | Reset/restore to default button |
Casing material | Aluminum housing, plastic panels |
Dimensions | 83 mm x 74 mm x 25 mm (H x W x D) |
Weight | 125 g |
Mounting options | Bottom and sideways DIN rail mounting slots |
Operating temperature | -40 °C to 75 °C |
Operating humidity | 10% to 90% non-condensing |
Ingress Protection Rating | IP30 |
MTBF | 310000 h |
Input | 1 x Digital Input |
Output | 1 x Digital Output |
Events | SMS, EMAIL, RMS |
CPU | Atheros Hornet, MIPS 24Kc, 400 MHz |
RAM | 64MB, DDR2 |
FLASH memory | 16MB SPI Flash |
