Ubiquiti - Campanello PoE+ da 12 MP per tutte le stagioni con rilevamenti AI potenziati, audio bidirezionale, display touch da 3", telecamera secondaria integrata e funzionalità di lettore di accesso integrate.
Code: ART-223732 - UVC-G6-Pro-Entry
CONTENUTO DELLA CONFEZIONE
Tech Detail Table
Tech Detail Table
Overview
Dimensions
220 x 49.3 x 29.6 mm
(8.7 x 1.9 x 1.2")
IR Night Vision
5 m (16 ft)
Face Recognition
Yes
Smart Detections (People, Vehicles, Animals)
Yes
Resolution
Main camera: 12MP
Package camera: 8MP
Field of View
Main camera:
H: 100°, V: 136.3°, D: 176.4° (12MP)
H: 70.9°, V: 127.5°, D: 147.4° (8MP)
Package camera: H: 66°, V: 51.7°, D: 78°
Audio
Two-way audio
Weatherproofing
IP55
Tamper Resistance
IK07
LCM IK04
Mounting
Wall mount, Gangbox mount plate, 20° wedge mount (Included)
Junction box (Optional)
NFC Card & Keyfob Access
Yes
PIN Access
Yes
Apple/Google Wallet
Yes
Mobile Unlock
Yes
Two-Way Intercom & Doorbell Access
Yes
UniFi Application Suite
Protect
Yes
Access
Yes
Performance
Networking Interface
GbE RJ45 port
Connectivity
BLE 4.1
NFC
Video
Image Settings
Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay, HDR
Max. Frame Rate
Main camera: 12MP, 20 FPS or
8MP, 30 FPS
Package camera: 3 FPS
Resolution
Main camera: 12MP, 3024 x 4096 (3:4) or
8MP, 2160 x 3840 (9:16)
Package camera: 8MP, 3264 x 2448 (4:3)
Optics
Sensor
Main camera: 12MP CMOS
Package camera: 8MP CMOS
Lens
Fixed focal length
Night Mode
Built-in IR LED illumination and IR cut filter
Hardware
Max. Power Consumption
18W
Supported Voltage Range
42—57V DC
Power Method
PoE+
Processor
Quad-core Arm® Cortex®-A53 based chip
Weight
360 g (12.7 oz)
Enclosure Material
Aluminum
Mount Material
Wall mount: Stainless steel
Gangbox mount plate: SGCC steel
Gangbox mount cover: Polycarbonate
Wedge mount: Aluminum
Display
Size
75 mm (3") diagonal
Screen Technology
Capacitive multi-touch
Luminance
Max. 1000 nits (Typical)
Screen Orientation
Portrait
Resolution
480 x 854 px
Button
(1) Ring button
(1) Factory reset
(1) Tamper switch
LEDs
R/G/B/W/Amber
Learn More
Ambient Operating Temperature
Device: -30 to 50° C (-22 to 122° F)
Display: -25 to 50° C (-13 to 122° F)
Ambient Operating Humidity
5 to 90% noncondensing
NDAA Compliant
Yes
Certifications
CE, FCC, IC
