QNAP NAS - 9-Bay 2U rackmount NAS, Intel® Xeon® E-2334 4 cores / 8 threads 3.4 GHz processor (boost up to 4.8 GHz), 16 GB ECC DDR4, 4 x 2.5"/3.5" SATA 6Gbps HDD/SSD + 5 x 2.5" U.2 NVMe/SATA 6Gbps, 2 x 10GBASE-T, 2 x 2.5GbE, 4 x USB 3.2 Gen2 ( USB-A), 1 x PCIe Gen4 x8, 550W redundant power supply, QuTS hero O.S. with ZFS, deduplication, compress, snapshots, optional fibre channel FC support
Code: ART-181522 4711103082300 TS-h987XU-RP-E2334-16G
The TS-h987XU-RP is powered by the next-gen Intel® Xeon® E-2344 quad-core processor, supports up to 128 GB DDR4 ECC memory, and provides an HDD/SSD hybrid storage architecture that balances performance and cost to deliver reliable server-grade performance. Running the ZFS-based QuTS hero operating system, the TS-h987XU-RP emphasizes data integrity with inline data deduplication, near-limitless snapshots, real-time SnapSync, and QSAL (QNAP SSD Antiwear Leveling) – providing an ideal storage solution that meets today’s business requirements for file servers, virtualization servers, VDI, and backup/restore.
Tech Detail Table
Tech Detail Table
| Backup function | Y |
| Chassis type | Rack (1U) |
| Cooling type | Active |
| Depth | 479 mm |
| Device class | Small & Medium Business |
| Ethernet LAN | Y |
| Ethernet LAN (RJ-45) ports | 4 |
| Ethernet LAN data rate supported (max) | 10000 Mbit/s |
| Ethernet LAN data rates | 100,1000,2500,5000,10000 Mbit/s |
| Fan diameter | 4 cm |
| Flash memory | 5000 MB |
| Height | 43.3 mm |
| Installed storage drive type | N |
| Internal memory | 16 GB |
| Internal memory type | DDR4 |
| LED indicators | HDD, LAN, Status |
| Maximum RAM supported | 128 GB |
| Memory form factor | UDIMM |
| Number of fans | 4 fan(s) |
| Number of power supply units | 2 |
| Number of storage drives supported | 9 |
| On/off switch | Y |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 40 °C |
| Package weight | 11.1 kg |
| PCI Express x8 (Gen 4.x) slots | 1 |
| Power supply unit (PSU) capacity | 250 W |
| Processor boost frequency | 4.8 GHz |
| Processor cache | 8 MB |
| Processor cores | 4 |
| Processor family | Intel Xeon E |
| Processor frequency | 3.4 GHz |
| Processor manufacturer | Intel |
| Processor model | E-2334 |
| Processor threads | 8 |
| RAID support | Y |
| Reset button | Y |
| Storage drive sizes supported | 2.5,3.5" |
| Storage drives installed | N |
| Supported storage drive interfaces | Serial ATA, U.2 |
| Supported storage drive types | HDD & SSD |
| Type | NAS |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 4 |
| USB port | Y |
| Weight | 8.43 kg |
| Width | 430 mm |
