MikroTik - RB5009UPr+S+ with Marvell Armada ARMv8 CPU (4-cores, 1.4GHz per core), 1GB of DDR4 RAM, 1GB NAND storage, 1x 2.5Gbit LAN (802.3af/at PoE-out and POE-in), 7x 1Gbit LAN (802.3af/at PoE-out and POE-in), 1x SFP+ port, RouterOS L5, IP66 compliant outdoor case, mounting kit (power supply NOT included)
Codice: ART-188726 EAN: 4752224008459 MPN: RB5009UPr+S+OUT
Mikrotik RB5009UPr+S+OUT. Standard di rete: IEEE 802.3af, IEEE 802.3at, Tipo di interfaccia Ethernet: 2.5 Gigabit Ethernet, Gigabit Ethernet. Versione USB: 3.2 Gen 1 (3.1 Gen 1). Produttore processore: Marvell, Modello del processore: 88F7040, Frequenza del processore: 1400 MHz. Colore del prodotto: Bianco. Consumi: 150 W, Tipologia alimentazione: PoE
Scheda Tecnica
Scheda Tecnica
| Altezza | 57 mm |
| Capacità memoria interna | 1 GB |
| Certificazione | CE, EAC, ROHS |
| Colore del prodotto | Bianco |
| Consumi | 150 W |
| Frequenza del processore | 1400 MHz |
| Intervallo temperatura di funzionamento | -40 - 70 °C |
| Jack DC-in | Sì |
| Larghezza | 222 mm |
| Manuale dell'utente | Sì |
| Modello del processore | 88F7040 |
| Modem USB compatibile con 3G/4G | No |
| Monitoraggio della temperatura | Sì |
| Monitoraggio della tensione | Sì |
| Numero di USB | 1 |
| Processore integrato | Sì |
| Produttore processore | Marvell |
| Profondità | 239 mm |
| Quantità di slot del modulo SFP+ | 1 |
| Quantità porte Ethernet LAN (RJ-45) | 8 |
| Quantità porte Power over Ethernet (PoE) | 8 |
| RAM installata | 1024 MB |
| SFP WAN | No |
| Sistema operativo incluso | RouterOS |
| Slot per scheda SIM | No |
| Standard di rete | IEEE 802.3af, IEEE 802.3at |
| Supporto Power over Ethernet (PoE) | Sì |
| Tempo medio tra guasti (MTBF) | 200000 h |
| Tipo di interfaccia Ethernet | 2.5 Gigabit Ethernet, Gigabit Ethernet |
| Tipologia alimentazione | PoE |
| Versione USB | 3.2 Gen 1 (3.1 Gen 1) |
| WAN DSL | No |
| WAN Ethernet | No |
