MARS Antenne è una società israeliana fondata nel 1994 e specializzata nella fornitura di antenne e soluzioni RF. In particolare MARS ha sviluppato una consolidata esperienza nella produzione di un ampio arco di prodotti tra cui antenne a pannello (Base Station e Subscriber) per applicazioni Wireless a lungo raggio; dispositivi a banda larga per applicazioni militari, dalla banda MF a HF fino alle microonde; antenne a microstriscia, dipoli, guide d'onda e così via: un'ampia gamma di soluzioni volte a soddisfare ogni esigenza nel campo delle radiofrequenze.

Richiedi Info Vuoi ricevere maggiori informazioni su questo prodotto? Contattaci subito!

Richiedi Info

Soluzioni
Prodotti
Approfondimenti

Categorie

Il nostro ecosistema

Chi Siamo

Dove Siamo

CALEARO ANTENNE SPA

Cambium Networks

FEITIAN TECHNOLOGIES

KEEPER SECURITY EMEA LTD

Kingston Technology

RevealSecurity Ltd

Ruckus Networks

Sierra Wireless

Western Digital

Contattaci

Filtri

reset filtri

Articoli 5

Mars Antennas--Cavo 1m RG142+ Connettorizzato N male - SMA male PROMO…

Mars Antennas

ART-152269

MPN: MC-N2S-RG142-1X

Connettorizzato N male - SMA male

ART-152269

Mars Antennas--Cavo 1m RG142+ Connettorizzato N male - SMA male PROMO…

Connettorizzato N male - SMA male

Brand: Mars Antennas

Codice: ART-152269

MPN

MC-N2S-RG142-1X

EAN -

Connettorizzato N male - SMA male

Brand: Mars Antennas

Codice: ART-152269

MPN

MC-N2S-RG142-1X

INFO

Mars Antennas--Antenna settoriale 90, 16 dBi 4.9-6.1 GHz PROMO FINO AD…

Mars Antennas

ART-152155

MPN: MA-WD55-DS16B

MA-WD55-DS16 - Base Station MARS Dual Slant ± 45 degrees 90° sector antenna features: Efficient and stable performance with 16 dBi of gain Full 4.9-6.1 GHz band coverage High Isolation ratio Compact size Optional Azimuth & Elevation Adjustable mount UV protected radome suitable for harsh environment installations Square shape Specifications: Electrical Frequency range 4.9 - 6.1 GHz Gain,typ. 16 dBi VSWR, max. 1.7:1 3 dB Beam-Width, H-Plane, typ. 90 ° 3 dB Beam-Width, E-Plane, typ. 8 ° Polarization Dual Slant ± 45º Port to Port Isolation - 30 dB Front to Back Ratio, min. -30 dB Input power, max 10 Watt Input Impedance 50 Ohm Lightning Protection DC Grounded Mechanical Dimensions (HxWxD) 370 x 370 x 40 mm (14.5”x 14.5”x 1.6”) Weight 1.8 kg Connector 2 x N-Type, Female Back Plane Aluminum protected through chemical passivation Radome UV Protected Plastic Mount MNT-22 Environmemtal Operating Temperature Range - 40°C to + 65°C Vibration According to IEC 60721-3-4 Wind Load 200 km/h (survival) Flammability UL94 Water Proofing IP-67 Humidity ETS 300 019-1-4, EN 302 085 (annex A.1.1) Ice and Snow 25mm radial (survival) Salt Fog According to IEC 68-2-11 Service Life >10 years

ART-152155

Mars Antennas--Antenna settoriale 90, 16 dBi 4.9-6.1 GHz PROMO FINO AD…

MA-WD55-DS16 - Base Station MARS Dual Slant ± 45 degrees 90° sector antenna features: Efficient…

Brand: Mars Antennas

Codice: ART-152155

MPN

MA-WD55-DS16B

EAN -

MA-WD55-DS16 - Base Station MARS Dual Slant ± 45 degrees 90° sector antenna features: Efficient and stable performance with 16 dBi of gain Full 4.9-6.1 GHz band coverage High Isolation ratio Compact size Optional Azimuth & Elevation Adjustable mount UV protected radome suitable for harsh environment installations Square shape Specifications: Electrical Frequency range 4.9 - 6.1 GHz Gain,typ. 16 dBi VSWR, max. 1.7:1 3 dB Beam-Width, H-Plane, typ. 90 ° 3 dB Beam-Width, E-Plane, typ. 8 ° Polarization Dual Slant ± 45º Port to Port Isolation - 30 dB Front to Back Ratio, min. -30 dB Input power, max 10 Watt Input Impedance 50 Ohm Lightning Protection DC Grounded Mechanical Dimensions (HxWxD) 370 x 370 x 40 mm (14.5”x 14.5”x 1.6”) Weight 1.8 kg Connector 2 x N-Type, Female Back Plane Aluminum protected through chemical passivation Radome UV Protected Plastic Mount MNT-22 Environmemtal Operating Temperature Range - 40°C to + 65°C Vibration According to IEC 60721-3-4 Wind Load 200 km/h (survival) Flammability UL94 Water Proofing IP-67 Humidity ETS 300 019-1-4, EN 302 085 (annex A.1.1) Ice and Snow 25mm radial (survival) Salt Fog According to IEC 68-2-11 Service Life >10 years

Brand: Mars Antennas

Codice: ART-152155

MPN

INFO

Mars Antennas--Antenna settoriale 120, 5 dBi, 4.9 - 6.1 GHz PROMO FINO…

Mars Antennas

ART-18538

MPN: MA-WE55-15B

MA-WE55-15 - Base Station MARS 120° Broadband Sector Antenna provides a cost effective solution for large scale WLL, WLAN, H-LAN, ISM, UNII, and Point-to-Multi-Point applications. Additional Features: - stable performance with 15 dBi of gain - small size allowing for easy blending with any environment - pole mount allowing for quick and easy installation and tilting adjustment - UV protected radome suitable for harsh environment installations Specifications: Electrical Frequency range 4.9 - 6.1 GHz Gain,typ. 15 dBi VSWR, max. 1.8:1 3 dB Beam-Width, H-Plane, typ. 120 ° 3 dB Beam-Width, E-Plane, typ. 8 ° Side Lobes, min. ETSI EN 302 085 V1.2.3 – CS1 Polarization Linear Vertical Cross Polarization, min. ETSI EN 302 085 V1.2.3 – CS1 Front to Back Ratio, min. ETSI EN 302 085 V1.2.3 – CS1 Input power, max 50 Watt Input Impedance 50 Ohm Lightning Protection DC Grounded Mechanical Dimensions (HxWxD) 573 x 95 x 53 mm (22.6"x3.7"x2.1") Weight 700 gr. Connector N-Type, Female Back Plane Aluminum; protected through chemical passivation Radome UV Protected, Plastic Mount MNT-22 Environmemtal Operating Temperature Range -40° C to +65° C Vibration According to IEC 60721-3-4 Wind Load 200 km/h (survival) Flammability UL94 Water Proofing IP-65 Humidity ETS 300 019-1-4, EN 302 085 (annex. A.1.1) Ice and Snow 10 mm radial (survival) Salt Fog According to IEC 68-2-11 Service Life > 10 years Standard Compliance ETSI EN 302 085 V1.2.3 – CS1 Ordering Options Antenna with mount MA-WE55-15 B

ART-18538

Mars Antennas--Antenna settoriale 120, 5 dBi, 4.9 - 6.1 GHz PROMO FINO…

MA-WE55-15 - Base Station MARS 120° Broadband Sector Antenna provides a cost effective solution for…

Brand: Mars Antennas

Codice: ART-18538

MPN

MA-WE55-15B

EAN -

MA-WE55-15 - Base Station MARS 120° Broadband Sector Antenna provides a cost effective solution for large scale WLL, WLAN, H-LAN, ISM, UNII, and Point-to-Multi-Point applications. Additional Features: - stable performance with 15 dBi of gain - small size allowing for easy blending with any environment - pole mount allowing for quick and easy installation and tilting adjustment - UV protected radome suitable for harsh environment installations Specifications: Electrical Frequency range 4.9 - 6.1 GHz Gain,typ. 15 dBi VSWR, max. 1.8:1 3 dB Beam-Width, H-Plane, typ. 120 ° 3 dB Beam-Width, E-Plane, typ. 8 ° Side Lobes, min. ETSI EN 302 085 V1.2.3 – CS1 Polarization Linear Vertical Cross Polarization, min. ETSI EN 302 085 V1.2.3 – CS1 Front to Back Ratio, min. ETSI EN 302 085 V1.2.3 – CS1 Input power, max 50 Watt Input Impedance 50 Ohm Lightning Protection DC Grounded Mechanical Dimensions (HxWxD) 573 x 95 x 53 mm (22.6"x3.7"x2.1") Weight 700 gr. Connector N-Type, Female Back Plane Aluminum; protected through chemical passivation Radome UV Protected, Plastic Mount MNT-22 Environmemtal Operating Temperature Range -40° C to +65° C Vibration According to IEC 60721-3-4 Wind Load 200 km/h (survival) Flammability UL94 Water Proofing IP-65 Humidity ETS 300 019-1-4, EN 302 085 (annex. A.1.1) Ice and Snow 10 mm radial (survival) Salt Fog According to IEC 68-2-11 Service Life > 10 years Standard Compliance ETSI EN 302 085 V1.2.3 – CS1 Ordering Options Antenna with mount MA-WE55-15 B

Brand: Mars Antennas

Codice: ART-18538

MPN

INFO

Mars Antennas 4x4 (Double Dual Slant 2xñ45ø) Base…

Mars Antennas

ART-109827

MPN: MA-WC54-2DS17B

ART-109827

Mars Antennas 4x4 (Double Dual Slant 2xñ45ø) Base…

Brand: Mars Antennas

Codice: ART-109827

MPN

MA-WC54-2DS17B

EAN -

Brand: Mars Antennas

Codice: ART-109827

MPN

INFO

Mars Antennas--Antenna 698 Mhz-6.5 GHz PROMO FINO AD ESAURIMENTO…

Mars Antennas

ART-75175

MPN: MA-VMB-5M

MARS Blade Antenna è un'antenna resistente, aerodinamica per l'uso in applicazioni mobili come treni, elicotteri, autobus o automobili. Bande di frequenza: 698-806[MHz], 806-960[MHz], 1.71-2.17[GHz], 2.3-2.7[GHz], 3.3-3.8[MHz], 4.9-6.5[MHz] Guadagno: min 2dBi, max 6dBi Polarizzazione: lineare, verticale Input power: 5 w Pattern Omni-Direzionale Connettore: maggnetic mount con connettore SMA(f) Dimensioni: 169 x 85 x 88 [mm] Peso: 150g

ART-75175

Mars Antennas--Antenna 698 Mhz-6.5 GHz PROMO FINO AD ESAURIMENTO…

MARS Blade Antenna è un'antenna resistente, aerodinamica per l'uso in applicazioni mobili come…

Brand: Mars Antennas

Codice: ART-75175

MPN

MA-VMB-5M

EAN -

MARS Blade Antenna è un'antenna resistente, aerodinamica per l'uso in applicazioni mobili come treni, elicotteri, autobus o automobili. Bande di frequenza: 698-806[MHz], 806-960[MHz], 1.71-2.17[GHz], 2.3-2.7[GHz], 3.3-3.8[MHz], 4.9-6.5[MHz] Guadagno: min 2dBi, max 6dBi Polarizzazione: lineare, verticale Input power: 5 w Pattern Omni-Direzionale Connettore: maggnetic mount con connettore SMA(f) Dimensioni: 169 x 85 x 88 [mm] Peso: 150g

Brand: Mars Antennas

Codice: ART-75175

MPN

INFO
